    F.S. 84 GTI ITBs, standalone, LSD, rounds, euro tails/bumps, coils, paint, etc

    08-20-2012 08:30 AM #1
    I hate to do this, but I am ready for a change and something newer.

    Price drop to $7000 or best offer. If you have any questions shoot me a pm I would be happy to discuss the car in greater detail.

    Thanks for looking
    -Chris

    Video clips at bottom of thread.





    Here are some additional images please excuse the dirt and unwaxed paint










    (strut bar removed for pic and I may be making a new one soon)



    just for fun the motor when I got the car




    Body
    Ppg jazz blue paint jambs, bay, etc
    Single round front end
    New oem fenders
    Bonrath badgless and grill spoiler
    crosshair rounds I forget what brand
    Euro rear panel and genuine Hella euro tails and bulb trays tails
    Shaved side molding holes and side markers
    Shaved hatch emblems and wiper
    Small chrome metal euro bumpers
    Single front wiper (both holes retained)
    Removed battery tray and some other brackets from engine bay
    20l motorcycle battery mounted in rear door card area with 0 gauge wire

    Interior
    Custom rear false floor with old Rockford fosgate 200a 4 channel amp mounted underneath
    Crappy head unit with front aux in
    6x9’s in the back false floor 3.5’s in the dash
    Custom Harness bar, with sparco wrap mount 4 point harnesses
    mkII gray recaro’s with power bases (no motors)
    Momo mod 69 suede wheel and hub extender
    Momo shift knob
    Wolfsburg horn button
    Recovered headliner and sunroof panel with black feltish material
    Silly skull door cards and shift knob ( I have the stock door cards)

    Suspension
    Bilsten threaded race shock bodies #500 front #450 rear
    Autotech hollow rear sway bar, no front swaybar
    Poly rear beam bushings
    Poly front control arm bushings
    Poly rear shock mounts
    Compbrake Spherical bearing front strut mounts
    Raceland front upper strut bar
    Raceland lower K bar
    Custom quick release rear strut bar
    Unix performance ball joint extenders
    Flipped tie rods
    Stich welded rear hatch area floor pans and strut towers
    Stich welded control arms

    Engine
    2.0 obdII aba block
    Balanced intermediate shaft (scch)
    ARP head studs with 9a metal HG
    Bertils ITB’s from super vee race car
    Matching Bertils Valve Cover
    Custom catch can with -12 an fittings
    autotech LW cam gear, and lw intermediate shaft gear
    TT race header modded with megaphone braided flex coupling and vband (tig welded)
    Custom Exhaust 2.25” with borla muffler (no cat)
    Megasquirt and spark v1
    Mil spec quick release engine bay body harness and complete new wiring all around
    Abf alternator bracket w aba alternator (manual tensioner)
    Aluminum under drive pulleys (modded 1.8t)
    Eurospec solid lifter casting head with
    Techtonics/Supertech 42x36 big valves, hd valve springs, Titanium retainers, Custom shim under bucket lifters, web 316 race cam

    Wheels/Transmission/Braking
    watanabe rs 14x6.5 with center caps JDM
    185x55x14 bct tires
    4k trans rebuilt by dave @ oldschool industries a few years but not many miles ago
    peloquin 3.94 diff .75 5th
    16v clutch and triple strapped pressure plate (grade 12 allen hardware)
    Usrt spherical short shift kit
    Eurospec lightweight flywheel
    Scch spherical shifter housing
    Wilwood dynalite forged calipers 10.1 mk3 front rotors (clears 14’s) mmp caliper carriers
    Rocco 16v rear discs
    Wilwood proportioning valves
    Manual brake conversion 23.5mm master cylinder, braided -4an lines throughout
    Last edited by chrisbmx68; 10-04-2012 at 09:51 AM.
    Reply With Quote Reply With Quote
  3. nothing-leaves-stock
    nothing-leaves-stock is offline
    Banner Advertiser nothing-leaves-stock's Avatar
    Join Date
    May 16th, 2006
    Location
    230 E. landis st coopersburg pa 18036
    Posts
    22,678
    Vehicles
    a few.
    08-20-2012 09:09 AM #2
    oh really?
    www.nothingleavesstock.com
    NLS's full line of parts on our online store!http://nothingleavesstock.com/online...=0&sort=normal
    Email us at sales@nothingleavesstock.com 230 E. landis st. Coopersburg PA 610 282 5487
    Reply With Quote Reply With Quote
  4. goin2fast
    goin2fast is offline
    Member goin2fast's Avatar
    Join Date
    Mar 23rd, 2006
    Location
    Doylestown Pa
    Posts
    7,182
    Vehicles
    Trying to remove everything OEM on 06 GTI
    08-20-2012 10:00 AM #3
    Say it aint so.
    Reply With Quote Reply With Quote
  5. Couch Gentleman
    Couch Gentleman is offline
    Member Couch Gentleman's Avatar
    Join Date
    Jan 14th, 2006
    Location
    Doylestown, PA
    Posts
    6,985
    Vehicles
    98 GTI
    Send a message via AIM to Couch Gentleman
    08-20-2012 01:04 PM #4
    Nothing Leaves Stock NLS
    230 E Landis St. Coopersburg, PA - (610)282-5487
    State Inspection & Oil Changes - Custom Turbo Setups - Engine Work - Welding - Fabrication
    Reply With Quote Reply With Quote
  6. taymk2
    taymk2 is offline
    Member taymk2's Avatar
    Join Date
    Oct 21st, 2001
    Location
    Middleburg Va
    Posts
    5,662
    Vehicles
    95 cabrio 08 jetta 01 mb 320 12 yukon xl
    08-21-2012 04:08 PM #5
    Reply With Quote Reply With Quote
  7. Aggro Crag
    Aggro Crag is offline
    Member Aggro Crag's Avatar
    Join Date
    Apr 23rd, 2005
    Location
    Boyertown, PA
    Posts
    6,271
    Vehicles
    87 gti, 96 jetta
    08-24-2012 12:45 PM #6
    Trade for a fixed gear bicycle?
    -Zac

    @feces
    Reply With Quote Reply With Quote
  8. chrisbmx68
    chrisbmx68 is offline
    Member chrisbmx68's Avatar
    Join Date
    Aug 14th, 2003
    Location
    Collegeville PA
    Posts
    11,578
    Vehicles
    2004 r32, 1991 318is
    Send a message via AIM to chrisbmx68
    08-24-2012 12:55 PM #7
    nope but I will trade you straight up for that fine mk2 you have.
    Reply With Quote Reply With Quote
  9. Aggro Crag
    Aggro Crag is offline
    Member Aggro Crag's Avatar
    Join Date
    Apr 23rd, 2005
    Location
    Boyertown, PA
    Posts
    6,271
    Vehicles
    87 gti, 96 jetta
    08-24-2012 01:05 PM #8
    PM sent
    -Zac

    @feces
    Reply With Quote Reply With Quote
  10. Couch Gentleman
    Couch Gentleman is offline
    Member Couch Gentleman's Avatar
    Join Date
    Jan 14th, 2006
    Location
    Doylestown, PA
    Posts
    6,985
    Vehicles
    98 GTI
    Send a message via AIM to Couch Gentleman
    08-28-2012 11:53 AM #9
    Nothing Leaves Stock NLS
    230 E Landis St. Coopersburg, PA - (610)282-5487
    State Inspection & Oil Changes - Custom Turbo Setups - Engine Work - Welding - Fabrication
    Reply With Quote Reply With Quote
  11. pentaxshooter
    pentaxshooter is offline
    Member pentaxshooter's Avatar
    Join Date
    Sep 3rd, 2009
    Location
    Charlotte, NC
    Posts
    3,120
    Vehicles
    2004.5 GLI
    Send a message via AIM to pentaxshooter
    08-28-2012 09:16 PM #10
    Tempting.
    Add me on FB and follow me on Instagram! | #TPG | #FLOSSfilthy | #V2LAB |

    Always looking for cars in the NC/VA area for feature shoots! PM me!
    Reply With Quote Reply With Quote
  12. Aggro Crag
    Aggro Crag is offline
    Member Aggro Crag's Avatar
    Join Date
    Apr 23rd, 2005
    Location
    Boyertown, PA
    Posts
    6,271
    Vehicles
    87 gti, 96 jetta
    08-29-2012 08:04 PM #11
    -Zac

    @feces
    Reply With Quote Reply With Quote
  13. pentaxshooter
    pentaxshooter is offline
    Member pentaxshooter's Avatar
    Join Date
    Sep 3rd, 2009
    Location
    Charlotte, NC
    Posts
    3,120
    Vehicles
    2004.5 GLI
    Send a message via AIM to pentaxshooter
    08-29-2012 08:28 PM #12
    Quote Originally Posted by Aggro Crag View Post
    Add me on FB and follow me on Instagram! | #TPG | #FLOSSfilthy | #V2LAB |

    Always looking for cars in the NC/VA area for feature shoots! PM me!
    Reply With Quote Reply With Quote
  14. Couch Gentleman
    Couch Gentleman is offline
    Member Couch Gentleman's Avatar
    Join Date
    Jan 14th, 2006
    Location
    Doylestown, PA
    Posts
    6,985
    Vehicles
    98 GTI
    Send a message via AIM to Couch Gentleman
    09-04-2012 11:47 AM #13
    Nothing Leaves Stock NLS
    230 E Landis St. Coopersburg, PA - (610)282-5487
    State Inspection & Oil Changes - Custom Turbo Setups - Engine Work - Welding - Fabrication
    Reply With Quote Reply With Quote
  15. chrisbmx68
    chrisbmx68 is offline
    Member chrisbmx68's Avatar
    Join Date
    Aug 14th, 2003
    Location
    Collegeville PA
    Posts
    11,578
    Vehicles
    2004 r32, 1991 318is
    Send a message via AIM to chrisbmx68
    09-05-2012 09:21 AM #14
    VIDEO?
    Microphone did not like loud noises at all seems like it was mostly just clipping.

    cold start
    disregard metal clanking noise my m50 valve cover was flying around in the trunk
    http://www.flickr.com/photos/5117025...in/photostream

    2nd and 3rd pull
    http://www.flickr.com/photos/5117025...n/photostream/

    highway merge
    http://www.flickr.com/photos/5117025...n/photostream/
    Reply With Quote Reply With Quote
  16. Take_it
    Take_it is online now
    Member Take_it's Avatar
    Join Date
    Jul 19th, 2010
    Location
    Connecticut
    Posts
    671
    Vehicles
    1984 vw gti (project), 1988 vw scirocco(sold), 2001.5 Audi s4(sold), 2001 beetle 1.8t(daily)
    09-14-2012 04:02 PM #15
    got an 01 santurin blue s4 ft. if your interest pm me with your number
    Reply With Quote Reply With Quote
  17. chrisbmx68
    chrisbmx68 is offline
    Member chrisbmx68's Avatar
    Join Date
    Aug 14th, 2003
    Location
    Collegeville PA
    Posts
    11,578
    Vehicles
    2004 r32, 1991 318is
    Send a message via AIM to chrisbmx68
    09-19-2012 02:45 PM #16
    a b5 is actually exactly what im looking for. Sending PM
    Reply With Quote Reply With Quote
  18. Couch Gentleman
    Couch Gentleman is offline
    Member Couch Gentleman's Avatar
    Join Date
    Jan 14th, 2006
    Location
    Doylestown, PA
    Posts
    6,985
    Vehicles
    98 GTI
    Send a message via AIM to Couch Gentleman
    10-03-2012 09:28 AM #17


    Nothing Leaves Stock NLS
    230 E Landis St. Coopersburg, PA - (610)282-5487
    State Inspection & Oil Changes - Custom Turbo Setups - Engine Work - Welding - Fabrication
    Reply With Quote Reply With Quote
  19. Couch Gentleman
    Couch Gentleman is offline
    Member Couch Gentleman's Avatar
    Join Date
    Jan 14th, 2006
    Location
    Doylestown, PA
    Posts
    6,985
    Vehicles
    98 GTI
    Send a message via AIM to Couch Gentleman
    10-03-2012 10:06 AM #18


    Nothing Leaves Stock NLS
    230 E Landis St. Coopersburg, PA - (610)282-5487
    State Inspection & Oil Changes - Custom Turbo Setups - Engine Work - Welding - Fabrication
    Reply With Quote Reply With Quote
  20. chrisbmx68
    chrisbmx68 is offline
    Member chrisbmx68's Avatar
    Join Date
    Aug 14th, 2003
    Location
    Collegeville PA
    Posts
    11,578
    Vehicles
    2004 r32, 1991 318is
    Send a message via AIM to chrisbmx68
    10-03-2012 10:08 AM #19
    h2o pics yesss, after this weekend you can add mk4 rear calipers to the list of mods.
    Reply With Quote Reply With Quote
  21. chrisbmx68
    chrisbmx68 is offline
    Member chrisbmx68's Avatar
    Join Date
    Aug 14th, 2003
    Location
    Collegeville PA
    Posts
    11,578
    Vehicles
    2004 r32, 1991 318is
    Send a message via AIM to chrisbmx68
    10-04-2012 09:51 AM #20
    Reply With Quote Reply With Quote
  22. Aggro Crag
    Aggro Crag is offline
    Member Aggro Crag's Avatar
    Join Date
    Apr 23rd, 2005
    Location
    Boyertown, PA
    Posts
    6,271
    Vehicles
    87 gti, 96 jetta
    10-08-2012 08:40 AM #21
    Aw yiss
    -Zac

    @feces
    Reply With Quote Reply With Quote
  23. Rheinland Pfalz
    Rheinland Pfalz is offline
    Member Rheinland Pfalz's Avatar
    Join Date
    Sep 20th, 2006
    Location
    Dublin PA
    Posts
    3,252
    Vehicles
    '85 coupe diesel, '01 avant
    10-09-2012 06:15 PM #22
    Ihsa nise cahr, yehs?
    Nothing Leaves Stock
    230 E Landis St. Coopersburg, PA - (610)282-5487
    State Inspection & Oil Changes - Custom Turbo Setups - Engine Work - Welding - Fabrication
    Cult Classic - Be there!
    Reply With Quote Reply With Quote
  24. chrisbmx68
    chrisbmx68 is offline
    Member chrisbmx68's Avatar
    Join Date
    Aug 14th, 2003
    Location
    Collegeville PA
    Posts
    11,578
    Vehicles
    2004 r32, 1991 318is
    Send a message via AIM to chrisbmx68
    10-17-2012 12:03 PM #23
    make some offers
    Reply With Quote Reply With Quote
  25. rudeboyevan
    rudeboyevan is offline
    Member rudeboyevan's Avatar
    Join Date
    Apr 27th, 2009
    Location
    The State of Rhode Island and Providence Plantations
    Posts
    1,410
    Vehicles
    2006 Rabbit (sold), Mk3 Jazz Blue (sold), Bugeye WRX Wagon
    Send a message via AIM to rudeboyevan
    10-17-2012 08:56 PM #24
    consider my jeans: creamed
    Reply With Quote Reply With Quote
  26. chrisbmx68
    chrisbmx68 is offline
    Member chrisbmx68's Avatar
    Join Date
    Aug 14th, 2003
    Location
    Collegeville PA
    Posts
    11,578
    Vehicles
    2004 r32, 1991 318is
    Send a message via AIM to chrisbmx68
    10-18-2012 04:36 PM #25
    engine bay harness connector

    Reply With Quote Reply With Quote
  27. Aggro Crag
    Aggro Crag is offline
    Member Aggro Crag's Avatar
    Join Date
    Apr 23rd, 2005
    Location
    Boyertown, PA
    Posts
    6,271
    Vehicles
    87 gti, 96 jetta
    10-18-2012 08:09 PM #26
    Quick release engine ftw
    -Zac

    @feces
    Reply With Quote Reply With Quote
  28. chrisbmx68
    chrisbmx68 is offline
    Member chrisbmx68's Avatar
    Join Date
    Aug 14th, 2003
    Location
    Collegeville PA
    Posts
    11,578
    Vehicles
    2004 r32, 1991 318is
    Send a message via AIM to chrisbmx68
    10-19-2012 09:18 AM #27
    It does make panties drop
    Reply With Quote Reply With Quote
  29. rabbitface
    rabbitface is offline
    Junior Member
    Join Date
    Dec 11th, 2006
    Posts
    52
    Send a message via AIM to rabbitface

    PM

    10-20-2012 04:07 PM #28
    You have pm.
    Reply With Quote Reply With Quote
  30. chrisbmx68
    chrisbmx68 is offline
    Member chrisbmx68's Avatar
    Join Date
    Aug 14th, 2003
    Location
    Collegeville PA
    Posts
    11,578
    Vehicles
    2004 r32, 1991 318is
    Send a message via AIM to chrisbmx68
    11-27-2012 01:17 PM #29
    The car is sold. It now lives in Colorado
    Reply With Quote Reply With Quote
  31. akabigmike2
    akabigmike2 is offline
    Member akabigmike2's Avatar
    Join Date
    May 4th, 2004
    Location
    DCIVW
    Posts
    4,332
    Vehicles
    84 gti,scion xd
    Send a message via AIM to akabigmike2

    F.S. 84 GTI ITBs, standalone, LSD, rounds, euro tails/bumps, coils, paint, etc

    12-05-2012 11:59 AM #30
    Who made that harness bar?
    DCIVW
    Reply With Quote Reply With Quote
  32. chrisbmx68
    chrisbmx68 is offline
    Member chrisbmx68's Avatar
    Join Date
    Aug 14th, 2003
    Location
    Collegeville PA
    Posts
    11,578
    Vehicles
    2004 r32, 1991 318is
    Send a message via AIM to chrisbmx68
    12-05-2012 12:13 PM #31
    not me I don't even remember who I got it from was like 5 years ago. I had planned on remaking it since I have my own welders now but it never happened.
    Reply With Quote Reply With Quote
+ Reply to Thread
« Previous Thread | Next Thread »

Posting Permissions

  • You may not post new threads
  • You may not post replies
  • You may not post attachments
  • You may not edit your posts

Forum Rules
